1-Channel Systems

Manner sensor telemetry has been developed with a focus on praxis-oriented applications and is therefore especially simple to operate. Using a non-contact induction procedure, the non-contact capture of amplified measuring signals from moving objects, especially shafts, is possible. During this procedure, a stator antenna captures the measured data from an antenna on the rotating component under measurement, without the need for any physical contact. Consequently, unbiased measuring results can be guaranteed. In the opposite direction, the measuring electronics on the moving component are supplied with energy via inductive coupling.


Thanks to the use of highly integrated microelectronics and the especially short set-up times due to simple and sophisticated mounting technology, these measuring systems are predestined for professional industrial applications. The systems have a thermal operating range of -55° to 180° Celsius. Their robust construction is suitable for extreme environmental conditions, such as use in oil or with accelerations of up to 100,000 g.


The powerful sensor telemetry system from Manner facilitates the economical and precise monitoring or measurement of static and dynamic parameters such as:

  • Torque
  • Pressure and tractive force
  • Bending moment
  • Acceleration
  • Temperature
  • Revolution speed


1-Channel - Datasheet

Download (749.9k)
